Maysee Technology Ltd.
LED Wall Washer Light & LED Underwater Light Manufacturer
 |
| Place of Origin: | Shenzhen, China |
| Brand Name: | Maysee |
| Certification: | CE/ROHS |
| Model Number: | MS-WW-RGB-L1 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Carton box or wooden case |
| Delivery Time: | 10-15 working days upon receipt of the deposit |
| Payment Terms: | T/T or WU or Paypal |
| Supply Ability: | Ex-works |
| Material: | Aluminum | Light Color: | RGB/R/G/B/W |
|---|---|---|---|
| LED Type: | Nichia | Control Mode: | DMX/on-off |
| Input Voltage: | 24VDC | IP Rating: | IP67 |
| Rated Power: | 6w | Warranty: | 3-year |
| High Light: | 6W linear led wall washer light,6W wall washer ip65,24VDC linear wall washer light |
||
5W Outdoor Linear LED Wall Washer Light With RGB color-change and 24VDC Input
Specification
| Model No. | MS-WW-RGB-L1 |
| Rated Power | 6W |
| Length | 500mm |
| Net Weight | 0.52kg |
| Q'ty of LEDs | 24pcs |
| Pixels per Bar | 4 pixels |
| DMX Channel per Bar | 4X3-CH |
| Pixel Pitch | 20.5mm |
| WidthxDepth | 32mmx38mm |
| Input Voltage | 24VDC |
| LED Brand | Nichia |
| Lens | Convex (102°) |
| Light Color | SMD (3-in-1) or mono-color |
| Material | anodized aluminum housing & polycarbonate Lens |
| Bar Intensity | 35Lm/W (RGB) |
| Operating Humidity | 0-99%RH |
| Operation Temperature | -20℃-70℃ |
| Life Time | 50,000 hrs |
| IP Rating | IP67 |
| Control Mode | DMX512 for RGB version/on-off switch for mono version |
| Mounting | surface-mounting |
| Warranty | 3-year |
Competitive Advantages
1. Innovative and compact
2. Exceptional design freedom
3. Easy to experience
Features:
1. Anodized aluminum housing and Nichia leds
2. 256 gradations for RGB individually
3. Display to 16,777,216 colors
4. Frame per second: >100 FPS at DMX512 control
5. Dimmable range: 0~255 steps at DMX512 dimming control
6. Built-in constanct-current circuit with PWM signal>400Hz
7. IP67
Application
Building outline, bridge, hotel, shopping mall, commercial area, park, etc.
Description
MS-WW-RGB-L1 series is an ultra slim LED profile which provides tremendous flexibility to integrate seamlessly with architectural structures. It brings urban landscapes to life with dynamic color-changing images. MS-WW-RGB-L series also illuminates facades and intrinsic building details with vivid, color-changing light to accentuate building structures. It comes with the standard length @250mm/500mm/1000mm/1500mm for various application. Made with durable, high-brightness and energy-efficient components. Well to create seamless lighting effects. With both RGB multi-color and mono-color for option. Compatible with DMX control for RGB version, just on-off switch control is easy to run the mono version.
